Modular Valves

10 results

Product	Maximum flow	Maximum Pressure	Operating pressure	Mounting surface	Operating Temperature	Connector Types	Compliance	Seal material	Recommended viscosity	Fluid compatibility

Atos HF Type Modular Valves, Size 06, Max Pressure 350 bar, Temperature Range -30°C to +70°C	60 l/min	350 bar	Ports P, A, B: 350 bar; Port T: 210 bar (DC solenoid), 160 bar (AC solenoid)	ISO 4401, Size 06	Standard seals: -30°C to +70°C; FKM seals (/PE): -20°C to +70°C; HNBR seals (/BT): -40°C to +70°C	DIN, AMP Junior Timer, Deutsch, or Lead Wire	CE, cURus, RoHS, REACH
Atos HMP/ HM/KM Type Modular Valves, Sizes 06 & 10, Max Pressure 350 bar, Temperature Range -40°C to +70°C	HMP: 35 l/min; HM: 60 l/min; KM: 120 l/min	350 bar		ISO 4401, Sizes 06 and 10	Standard seals: -30°C to +70°C; FKM seals (/PE): -20°C to +70°C; HNBR seals (/BT): -40°C to +70°C		RoHS Directive 2011/65/EU, REACH Regulation (EC) No. 1907/2006			Mineral oils (DIN 51524), Flame-resistant fluids (HFDU, HFDR, HFC)
Atos HS/KS Type Modular Valves, Sizes 06 & 10, Max Pressure 350 bar, Temperature Range -40°C to +70°C	HS: 40 l/min; KS: 80 l/min	HS: 350 bar; KS: 315 bar		ISO 4401, Sizes 06 and 10	NBR: -30°C to +70°C; FKM (/PE): -20°C to +70°C; HNBR (/BT): -40°C to +70°C		RoHS Directive 2011/65/EU, REACH Regulation (EC) No. 1907/2006			Mineral oils (DIN 51524), Flame-resistant fluids (HFDU, HFDR, HFC)
Atos HG/KG/JPG Type Modular Valves, Sizes 06–25, Max Pressure 350 bar, Temperature Range -40°C to +80°C	HG: 50 l/min; KG: 100 l/min; JPG-2: 250 l/min; JPG-3: 300 l/min	HG: 350 bar; KG and JPG: 315 bar		ISO 4401, Sizes 06, 10, 16, 25	Standard seals: -30°C to +80°C; FKM (/PE): -20°C to +70°C; HNBR (/BT): -40°C to +70°C		RoHS Directive 2011/65/EU, REACH Regulation (EC) No. 1907/2006			Mineral oils (DIN 51524), Flame-resistant fluids (HFDU, HFDR, HFC)
Atos HC/KC/JPC Type Modular Valves, Sizes 06–16, Max Pressure 350 bar, Temperature Range -40°C to +80°C	HC: 50 l/min; KC: 100 l/min; JPC: 200 l/min	350 bar		ISO 4401, Sizes 06, 10, 16	Standard seals: -30°C to +80°C; FKM (/PE): -20°C to +70°C; HNBR (/BT): -40°C to +70°C		RoHS Directive 2011/65/EU, REACH Regulation (EC) No. 1907/2006			Mineral oils (DIN 51524), Flame-resistant fluids (HFDU, HFDR, HFC)
Atos DHQ Type Modular Valves, Size 06, Max Pressure 250 bar, Temperature Range -40°C to +70°C	Regulated flow: 1.5–24 l/min; Free flow: 40 l/min	250 bar		ISO 4401-03-02-0-05	Standard seals: -30°C to +70°C; FKM (/PE): -20°C to +70°C; HNBR (/BT): -40°C to +70°C		CE to Low Voltage Directive 2014/35/EU, RoHS Directive 2011/65/EU, REACH Regulation (EC) No. 1907/2006			Mineral oils (DIN 51524), HFC fluids with appropriate seal selection
Atos HQ/KQ/JPQ Type Modular Valves, Sizes 06–25, Max Pressure 350 bar, Temperature Range -40°C to +80°C		350 bar (HQ, JPQ), 315 bar (KQ)		ISO 4401-03, ISO 4401-05, ISO 4401-07, ISO 4401-08	Standard seals: -30°C to +70°C; FKM (/PE): -20°C to +80°C; HNBR (/BT): -40°C to +60°C		RoHS Directive 2011/65/EU, REACH Regulation (EC) No. 1907/2006			Mineral oils (DIN 51524), flame-resistant fluids (HFDU, HFDR, HFC)
Atos HR/KR/JPR Type Modular Valves, Sizes 06–25, Max Pressure 350 bar, Temperature Range -40°C to +80°C				ISO 4401-03 to ISO 4401-08, depending on valve size.	Standard seals: -30°C to +80°C. FKM (/PE): -20°C to +70°C. HNBR (/BT): -40°C to +70°C.		RoHS Directive 2011/65/EU, REACH Regulation (EC) No. 1907/2006			Mineral oils (DIN 51524), HFC fluids with compatible seals.
Atos HJ-012 Type Modular Valve Plate, Size 06, Max Flow 40 l/min, Max Pressure 250 bar, Temperature Range -20°C to +80°C	Up to 40 l/min.	250 bar.		ISO 4401-03-02-0-05, with ports P, T, A, and B (Ø 7.5 mm max).	Standard seals: -20°C to +70°C. FKM (/PE option): -20°C to +80°C.		ISO 4401 standards, DIN fluid contamination class 21/19/16.	NBR (standard), FKM (/PE option).	15–100 mm²/s at 40°C.	Mineral oils (DIN 51524), hydraulic fluids with specific compatibility.
Atos HMU & RR Type Modular Valves, Size 06, Max Flow 4 l/min, Max Pressure 350 bar, Temperature Range -20°C to +80°C	4 l/min for both HMU and RR valves.	HMU: 350 bar. RR: 250 bar.		ISO 4401-03-02-0-05, with ports P, T, A, and B (Ø 7.5 mm max).	- Standard seals: -20°C to +70°C. - FKM (/PE): -20°C to +80°C.		ISO 4401 standards, RoHS, and REACH regulations.			Mineral oils (DIN 51524), hydraulic fluids with specific compatibility.
