Siemens SIMATIC S7-1200, SB 1231 Analog Input Signal Board, 4 Analog Inputs (±10 V / 0–20 mA, 14-bit), 6ES7231-4HD50-0XB0

Part Number : 6ES7231-4HD50-0XB0

Brand :
Siemens

The SIMATIC S7-1200 SB 1231 analog input signal board adds 4 × 14-bit voltage or current inputs to the CPU in a compact plug-on format.

View all

KWD 23.500

Quantity
Description
Specifications
Downloads
Related products

Description

Siemens SB 1231 AI 4x14-bit signal board adds four high‑resolution analog inputs to SIMATIC S7-1200 G2 CPUs without increasing the overall module width. Each channel can be configured for voltage ranges of ±10 V, ±5 V or ±2.5 V, or current ranges of 0–20 mA and 4–20 mA, with 14‑bit resolution. The compact 15 × 62 × 63 mm board plugs directly onto the front of the CPU, providing a space‑saving way to acquire precise process values from transmitters and sensors.

Key Features

• Compact SB 1231 analog input signal board for SIMATIC S7-1200 G2 CPUs • 4 configurable analog inputs with 14-bit resolution • Voltage ranges ±10 V, ±5 V, ±2.5 V selectable per channel • Current ranges 0–20 mA or 4–20 mA selectable per channel • Typical power loss approx. 1.4 W at 24 V DC supply • Small 15 × 62 × 63 mm board plugs directly onto the CPU front • Ideal for precise acquisition of process values in space?constrained panels

Downloads

6ES72314HD500XB0_datasheet_en.pdf

pdf
Download

Product overview for SIMATIC S7-1200-01.pdf

pdf
Download

Specifications

Product Type
SB 1231 analog input signal board, AI 4x14 bit
Number of analog inputs
4 differential analog inputs
Input signal ranges
±10 V, ±5 V, ±2.5 V; 0–20 mA or 4–20 mA
Resolution
14‑bit A/D conversion per channel
Rated supply voltage
24 V DC via CPU (20.4…28.8 V DC)
Typical power loss
Approx. 1.4 W
Dimensions (W×H×D)
Approx. 15 × 62 × 63 mm
Operating Temperature
−20 °C…60 °C (depending on mounting orientation)
