Wika In-Line Diaphragm Seal981.10, For Flange Connection, Cell-Type

Part Number : 981.10

Brand :
WIKA

Process connection For flanges following EN 1092-1 / ASME B 16.5 Nominal sizes see drawing and tables Sealing faces, Form B1 or ASME RF 125 ... 250 AA Pressure rating PN 6 ... 400 or class 150 ... 2500

View all
Quantity
Description
Downloads
Related products

Description

Process connection For flanges following EN 1092-1 / ASME B 16.5 Nominal sizes see drawing and tables Sealing faces, Form B1 or ASME RF 125 ... 250 AA Pressure rating PN 6 ... 400 or class 150 ... 2500 Pressure ranges Preferably assembled on pressure gauges NS 63, 100, 160 or pressure transmitters, measuring ranges 0 ... 0.6 to 0 ... 400 bar Body and material of wetted parts Stainless steel (AISI 316L) Measuring instrument connection Pressure gauge or transmitter directly welded, process pressure transmitter with threaded adapter System fill fluid KN2, Silicone oil Options Process connection Sealing faces per EN 1092-1, Form B2 or per ASME B 16.5, RF 125 AA, 500AA, RFSF; EN 1092-1 groove and tongue; projection and recess; ASME B 16.5 snap ring groove Form RJF (limited for special materials, please inquired Flame arrester approved for Zone 0 Measuring instrument connection Capillary, when ordering please specify: length of capillary Cooling tower (for process temperature >140°C) Material of wetted parts Stainless steel 1.4435, 1.4541, 1.4571, 1.4462, Monel 400, Hastelloy C276, Inconel 600, Incoloy 825, tantalum, Hastelloy B2, C4, C22 and nickel Capillary Custom lengths between 1 and 15 m Soft polyethylene or PTFE armour

Applications

• For direct, permanent installation in pipelines • For flowing, pure and aggressive media • Chemical process industry • Petrochemical industry

Special features

• Completely round, no corners and edges • For direct installation between two flanges • Wide choice of special materials

Downloads

981.10 Data sheets.pdf

pdf
Download

981.10 Operating instructions.pdf

pdf
Download

981.10 Technical information.pdf

pdf
Download
