Part Number : 970.10, 970.11, 970.12
Brand :
![WIKA]()
Process connection Stainless steel 1.4571 Model 970.10: G ½ B male thread Model 970.11: G ½ B male running nut Model 970.12: G ½ female union nut
View all
Description
Process connection Stainless steel 1.4571 Model 970.10: G ½ B male thread Model 970.11: G ½ B male running nut Model 970.12: G ½ female union nut Pressure rating PN 600 Pressure ranges 0 ... 10 to 0 ... 600 bar Capsule sensor Stainless steel 1.4571, welded with body Dimension: 75 x 13 x 6 mm Instrument connection Stainless steel 1.4571, G ½ female per EN 837-1 Options Process connection Model 970.10: G ¾ B, M20 x 1.5 male Model 970.11: G ¾ B, M20 x 1.5 male Model 970.12: G ¾, G 1 female Capsule sensor Dimension: 100 x 18 x 7 mm (requires minimum ¾ in. process connection) Instrument connection Capillary (welded with body) and gauge adapter G ½ female to fit surface mounting bracket complete of stainless steel Cooling tower (for directly mounted gauge when fluid temperature > 100 °C)
Applications
• For flowing, heterogeneous media • Suitable for high pressures up to 600 barSpecial features
• Compact size • Oval capsule sensor with internal support for stabilization • Immersed directly in the mediumRelated Products
![]()
