WIKA Capsule Pressure Gauge Model 632.50.100, Stainless Steel, Dial Size 100 mm / 4", Range 0…400 mbar, Capsule Element for Gaseous Media, Lower Mount 1/2 NPT, 39909315
Part Number : 39909315
Brand :
![WIKA]()
WIKA 632.50.100 capsule pressure gauge for low pressure measurement of gaseous, Stainless Steel dry and aggressive media in the process industry, with 100 mm dial, 0…400 mbar scale, lower-mount 1/2 NPT connection and laminated safety glass window to EN 837-3.
View all
KWD 231.000
Description
The WIKA 632.50.100 capsule pressure gauge is a process-industry series instrument designed for precise measurement of low pressures up to 400 mbar in gaseous, dry and aggressive media. Its capsule measuring system, case, bezel and movement are completely manufactured from stainless steel for maximum corrosion resistance, while the NS 100 mm dial, laminated safety glass window and clear 0…400 mbar scale ensure excellent readability on site. Built to EN 837-3 safety level S1 and featuring a lower-mount 1/2 NPT process connection with blow-out disc at the back, the gauge delivers reliable indication in demanding chemical, petrochemical, pharmaceutical and power applications. With standard ambient and medium temperature capability and IP54 ingress protection, it offers a robust, maintenance-friendly solution for low-pressure monitoring in the process industry.
Key Features
• Capsule pressure gauge for process
and industrial low-pressure measurement
• Model 632.50, dial size 100 mm /
4" with clear 0…400 mbar scale
• Measuring system, case, bezel ring
and movement all in stainless steel for high corrosion resistance
• Capsule element design optimized
for low pressures of gaseous, dry and aggressive media
• Lower-mount 1/2 NPT process
connection for easy installation in standard process lines
• Case with blow-out disc at the
back to improve safety in fault conditions
• Laminated safety glass window for
enhanced operator protection
• Accuracy class 1.6 for reliable
indication of low pressures
• IP54 ingress protection and single packing with WIKA-labelled inner and outer packaging
Typical Applications
• Low-pressure measurement of dry
and gaseous process media in chemical and petrochemical plants
• Corrosion-resistant pressure
indication in pharmaceutical and biotechnology systems
• Monitoring draft, vacuum and
slight overpressure in air, flue-gas and ventilation systems
• General process and industrial
applications where stainless steel capsule gauges are required
• OEM equipment and skid packages
needing compact, robust low-pressure indication
Specifications
