WIKA Bourdon Tube Pressure Gauge Model 232.50.160, Stainless Steel Case & Wetted Parts, Dial Size 160 mm / 6", 0…25 bar, Dry Case, Lower Mount 1/2 NPT, Laminated Safety Glass Window, IP65, 84281372
Part Number : 84281372
Brand :
![WIKA]()
WIKA 232.50 bourdon tube pressure gauge with 160 mm / 6" dial, 0…25 bar range and lower-mount 1/2 NPT connection, stainless-steel parts, supplied dry (without filling) for accurate, robust pressure indication in demanding industrial and process applications.
View all
KWD 110.250
Description
The WIKA 232.50 bourdon tube pressure gauge is a heavy-duty, all-stainless-steel instrument for industrial and process applications where reliability and corrosion resistance are critical. With a large 160 mm / 6" dial and 0…25 bar scale, it provides clear local indication even from a distance, while the stainless-steel measuring system and 316L pressure element offer excellent resistance to aggressive media and harsh environments. The gauge is supplied with a dry case (no filling) and features a lower-mount 1/2 NPT process connection for straightforward installation on manifolds, lines and equipment. A laminated safety glass window, red set pointer on the dial and IP65 ingress protection support safe, long-term operation at medium temperatures up to 200 °C and ambient conditions down to −40 °C.
Key Features
• All-stainless-steel bourdon tube
pressure gauge for industrial and process service
• Model 232.50 with large dial size
160 mm / 6" for excellent readability
• 0…25 bar range suitable for a wide
variety of general pressure applications
• Stainless-steel measuring system
and 316L pressure element for high corrosion resistance
• Dry case (without liquid filling)
for standard vibration conditions and easy handling
• Lower-mount 1/2 NPT process
connection for quick installation on standard process nozzles
• Laminated safety glass window to
improve operator safety and durability
• Red set pointer on dial for quick
visual indication of target or alarm pressure
• IP65 ingress protection for dusty
and splash-prone environments
• Individual serial number and QR code on dial for traceability and asset management
Typical Applications
• General pressure monitoring in
chemical and petrochemical plants
• Pump, compressor and hydraulic
system pressure indication
• Pressure measurement on process
lines, manifolds and utility systems
• Industrial machinery, OEM skids
and equipment packages
• Applications requiring corrosion-resistant stainless-steel gauges with large, easy-to-read dials
Specifications
