Wika Bourdon Tube Pressure Gauge Model 232.50.100, 0...10000 PSI, 100 mm (4") Dial, 1/2" NPT Connection, Lower Back Mount, Stainless Steel Body & Wetted Parts, Class 1.0, 84287888
Part Number : 84287888
Brand :
![WIKA]()
Wika Bourdon Tube Pressure Gauge Model 232.50.100, 0...10000 PSI, 100 mm (4") Dial, 1/2" NPT Connection, Lower Back Mount, Stainless Steel Body & Wetted Parts, Class 1.0
View all
KWD 38.000
Description
Wika Model 232.50.100 Bourdon tube pressure gauge with 0...10000 PSI measuring range, 100 mm (4") stainless steel case and dial, 1/2" NPT lower back mount process connection and stainless steel 316L wetted parts. The gauge provides a dual psi/bar scale with red inner bar scale, accuracy class 1.0, laminated safety glass window, IP65 ingress protection and is suitable for ambient temperatures from -40…+60 °C and media temperatures up to +200 °C.
Features
• Full stainless steel case and wetted parts for aggressive media • 100 mm (4") dial with dual psi/bar scale (red inner scale) • Measuring range 0...10000 PSI for process and utility lines • 1/2" NPT lower back mount process connection • Accuracy class 1.0 (EN 837-1 / ASME B40.100) • Laminated safety glass window with high impact resistance • IP65 ingress protection • Ambient temperature range -40…+60 °C, medium temperature up to +200 °CApplications
• Chemical and petrochemical process lines • Oil and gas skids and utility stations • Water and wastewater treatment plants • Power generation and boiler auxiliaries • General industrial machinery and OEM equipment • Compressed air, gas and hydraulic circuitsBenefits
• Long service life in corrosive and harsh environments • Reliable measurement thanks to robust Bourdon tube system • Large 100 mm dial improves readability from a distance • Standardised 1/2" NPT lower back mount simplifies replacement and stocking • Clear dual scale reduces operator errorSpecifications
