Spirax Sarco Compact Trapping Station, made with Stainless Steel, STS17.2

Part Number : STS17.2

Brand :
Spirax Sarco

Compact pipeline connector steam trapping station with isolation and strainer.

View all
Quantity
Description
Specifications
Downloads
Related products

Description

The STS17.2 compact pipeline connector steam trapping station has been designed to provide a convenient ready to install trapping solution, which includes: upstream and downstream isolation valves, body incorporating quickfit connector + strainer and check valve blanking plug. It is compatible with various Spirax Sarco steam traps. Integral sensor type SSL1 (steam only) or WLSL1 (for waterlogging) for use with R1C or WLSL1 with DIODE for use with RI6C are available as optional extras, to enable operational monitoring of the steam trap. Please note that the optional Spiratec SSL1 and WLSL1 sensors must not be fitted when the STS17.2 is installed in a vertical application. BDV1 blowdown valve is also available for cleaning the strainer during operation. Care should be taken when using the BDV1 blowdown valve as the discharge may be hot. Please note that a BDV1 cannot be used when a Spiratec sensor has been chosen to be part of the unit. Retrofit double isolation valve and spool piece to convert a single upstream isolation version to double isolation. Insulation jacket is available to reduce heat loss and energy wastage. Their available sizes includes ½", ¾" and 1" screwed BSP, NPT or socket weld, ½", ¾" and 1" ASME 150 and ASME 300 and DN15, DN20 and DN25 flanged EN 1092 PN40. The STS17.2 is available in Single, Double or Double Block and Bleed variations.

Features

- Upstream and downstream isolation valves - Integrated strainer - Stainless steel construction - Compatibility with Spirax Sarco steam traps

Downloads

STS172-TI-P128-22-EN.pdf

pdf
Download

STS172-TI-F01-37-EN.pdf

pdf
Download

STS172-IM-P128-23-EN.pdf

pdf
Download

Specifications

Pressure rating
PN40, Max 17.5 bar
Material
Choose a housing material that is not corroded by the media and environment , and can withstand the temperatures and pressures. Check out our chemical resistance chart.
Stainless steel ASTM A351 Gr. CF8
Sizes
DN15(½"), DN20( ¾") and DN25(1")
Optional Features
Spiratec sensor, blowdown valve
Certification
EN 10204 3.1 Certified
