Sanhua MCHE Light Commercial Condenser & Evaporator Coils

Brand :
Sanhua

MCHE microchannel coils for light commercial condensers and evaporators provide high efficiency with low refrigerant charge.

View all
Quantity
Description
Specifications
Downloads
Related products

Description

Sanhua MCHE condenser coils for light commercial units use flat multi-port aluminum tubes and louvered fins to deliver high heat transfer performance in a compact footprint. The microchannel construction reduces refrigerant charge and weight compared with conventional fin-and-tube heat exchangers while offering low air-side pressure drop. A wide range of tube widths, port counts and fin geometries is available to optimise condensers and evaporators for rooftop units, packaged systems and light commercial chillers.

Key Features

• Flat multi-port aluminum tube design • Louvered fin geometry for high transfer • Compact coil footprint for tight spaces • Lower refrigerant charge than fin-and-tube • Reduced coil weight for easier handling • Low air-side pressure drop • Available in multiple tube and fin combinations

Downloads

Sanhua Datsheet Light Commercial Condenser & Evaporator.pdf

pdf
Download

Specifications

Product Type
MCHE coil
Application
Light commercial
Tube width
12–32 mm
Tube height
1.0–2.0 mm
Port count
10–32 ports
Fin width
12–32 mm
Fin height
6.5–11.4 mm
FPI options
16–26 FPI
