Saint Gobain Sani-Tech STHT-80 Silicone Tubing for High Pressure Applications, 3.2 mm ID x 6.4 mm OD, 7.5 mtrs roll, STHT-80-125-2
Part Number : STHT-80-125-2
Brand :
![Saint Gobain]()
Saint Gobain Sani-Tech STHT-80 Silicone Tubing STHT-80-125-2 is a premium platinum-cured silicone tubing designed for high burst pressure and vacuum applications. This high-durometer tubing surpasses typical silicone tubing in pressure resistance, eliminating the need for costly braid reinforcements in some cases. STHT®-80 offers best-in-class performance, achieving the highest burst pressure rating.
MOQ - 20 rolls
View allKWD 90.000
Description
Sani-Tech® STHT®-80 is a premium platinum-cured silicone tubing designed for high burst pressure and vacuum applications. This high-durometer tubing surpasses typical silicone tubing in pressure resistance, eliminating the need for costly braid reinforcements in some cases. STHT®-80 offers best-in-class performance, achieving the highest burst pressure ratings among comparable products, while remaining vacuumcompatible and cost-effective. STHT®-80 tubing offers a high level of transparency for easy visual identification of activity within the fluid path. This property greatly assists in applications which require visual cues and observation for success. Sani-Tech® STHT®-80 is manufactured in an ISO Class 7 cleanroom from platinum-cured silicone materials and tested to a variety of specifications. Standard coil length is 25 feet. 50 foot coils available by adding "F" to the end of the part number. 100 foot coils available by adding "H" to the end of the part number.
Features / Benefits
• Higher burst pressure than typical fluid transfer tubing
• Increased flow rates
• Does not collapse in vacuum conditions
• High level of transparency
• Reduces pulsation downstream of pumping
• Full extractables report per BioPhorum Operations Group (BPOG) protocol
• Technical dossier available
• Available with ValPlus™ certification
Typical Applications
• Fill finish fluid transfer
• Pressurized fluid transfer
• Hydrostatic pressure from large stainless steel vessels
• Sterile filtration integrity test / PUPSIT
• High-viscosity concentrated flow streams
General Sterilization Methods
• Autoclavable
• Irradiation (gamma and x-ray) - up to 50 kGy
• Gas – ethylene oxide
Downloads
