Mitutoyo 526-125-20 Mechanical Dial Bore Gauge for extra-small holes, 10 to 18 mm, 2-point

Part Number : 526-125-20

Brand :
Mitutoyo

The bore gauge is mechanically powered. Use it to measure the diameters of extra-small holes.

View all

KWD 105.710

Quantity
Description
Specifications
Related products

Description

Mitutoyo 526-125-20 Offers?Use the Mitutoyo 526-125 Mechanical Dial Bore Gauge for extra-small holes to accurately measure miniscule targets. With 8 anvils, 1 needle and a 2-point design, it allows you to achieve quick, precise results.FeaturesAccurately measures extra-small hole diameters in millimetersWith 8 anvils and 1 needle for precise readingsMechanical with a clear, easy-to-read dial (2019SB-10)Compatible with 215-120-10 bore gauge stand (not included) for measurement of multiple small holesRadial displacement of split-ball contact is converted to axial displacement of measuring rod2-point design

Specifications

Minimum Metric Measurement
10 mm
Accuracy
4 μm
Maximum Metric Measurement
18 mm
Graduation
0.001 mm
Supported Measurement Unit(s)
Metric
Indication stability
2 μm
Graduation Measurements
Millimeters
Maximum Probe Depth
62 mm
