Mitutoyo 500-175-30 Digimatic Caliper, 0 to 6"/ 0 to 150 mm, carbide OD and ID

Part Number : 500-175-30

Brand :
Mitutoyo

The absolute encoder technology offered by the 500 series allows the caliper to keep track of its origin point once set. This caliper features an SPC data output, a measuring range of 0 to 6"/ 0 to 150 mm and carbide-tipped jaws for measurement of inside and outside diameter.

View all

KWD 92.620

Quantity
Description
Specifications
Related products

Description

Mitutoyo 500-175-30 Offers Features Large and clear LCD readout The ZERO/ABS key allows the display to be zero-set at any slider position along the scale for incremental comparison measurements It will allow return to the absolute (ABS) coordinate and display of the true position from the origin point (usually jaws-closed point) Optional data Hold Unit

Specifications

Accuracy
±.001"
Range
0 to 6"/ 0 to 150 mm
Resolution
.0005"/ 0.01 mm
Repeatability
0.01 mm / .0005"
Display
LCD
Length standard
ABSOLUTE electrostatic capacitance type linear encoder
Max. response speed
Unlimited
Battery
SR44
Battery Life
Approx. 3.5 years under normal use
