Mitutoyo 201-101 Dial Snap Series 201 Gauge 0-25mm
Part Number : 201-101
Brand :
![Mitutoyo]()
KWD 96.370
Description
Mitutoyo 201-101 Dial Snap Series 201 Gauge 0-25mm The Mitutoyo 201-101 Dial Snap Gauge measures within the 0-25mm range. Features: Designed for quick GO/NG judgment of diameters of cylinders and shafts in machining processes. Dial indicator is optional. Anvil retracting stroke: .078”/2mm Anvil positioning range: 1”/25mm Wide (.53 x .47”/13.5 x 12mm), flat carbide anvils. Both front edges of the anvil are chamfered for easy insertion. Technical Data: Accuracy: Refer to the list of Specifications Anvil retracting stroke:.078”/2mm Anvil positioning range: 1”/25mm Anvil flatness: .00004”/1µm
