Mitutoyo 169-207 Series 169 Disk Micrometer with non-rotating spindle, 75 to 100 mm

Part Number : 169-207

Brand :
Mitutoyo

The disk micrometer allows you to measure root tangent lengths of select gears. It is designed with a non-rotating spindle to prevent torque on the workpiece.

View all

KWD 87.220

Quantity
Description
Specifications
Related products

Description

Mitutoyo 169-207 Offers?The Mitutoyo 169-207 Series 169 Disk Micrometer can be used to easily and accurately determine the root tangent length of spur and helical gears. The analog micrometer is designed with a ratchet stop to provide constant force during measuring to meet your needs.FeaturesAccurately measures the root tangent length of helical and spur gearsSpindle features a non-rotating design to prevent torque on the workpieceDesigned with a standard bar to meet your needsRatchet stop provides constant force for optimal resultsDesigned with a flatness of 1 &?igrave;m and a parallelism of 6 ?m

Specifications

Product Width
Measuring disk diameter: 0.79" (20 mm)
Measurement Range
75 to 100 mm with 0.01 mm graduations
Product Length
4.4" (112 mm)
Supported Measurement Unit(s)
Metric
Product weight
14.1 oz (400 g)
Accuracy
±6 μm
Power Source
Non-powered
