Micronics Portaflow 222 and 333 Portable Clamp-on Flow & Heat Meter, PF333/PF222

Part Number : PF333/PF222

Brand :
Micronics

The Portaflow 333 is a more advanced model, ideal for applications requiring energy measurements and detailed data logging, while the Portaflow 222 is suited for simpler flow measurement tasks.

View all
Quantity
Description
Specifications
Downloads
Related products

Description

Our portable flow and energy meter solutions are ultrasonic, clamp on and non-invasive, for closed pipe applications. This means no interruption to process and no downtime whilst the portable flow and energy meters are installed. The Portaflow range brings simplicity to the non-invasive measurement of liquid flow and hydronic energy. Portaflow offers the user quick and accurate flow and energy measurement. And with its easy to follow menu and simple set up results can be achieved within minutes of opening the case!

Product Overview

• Ultrasonic, cross-correlation transit time method for flow measurement and PT100 Class B 4 wire for temperature measurement. • Heat/Energy calculation is designed to comply with EN1434 section 6. • Flow Range – 0.1m/sec to 10m/sec bi-directional • Display – 64 x 240 pixels graphic display • Set-up via 16 key control panel • ‘A’ Transducers in mounting rail:– 13mm OD to 115mm OD pipes • ‘B’ Transducers in mounting rail:– 50mm OD to 2000mm OD pipes. • Battery or mains operation • Rechargeable NiMH battery • Battery Life – 14 hours (2.5 hours charge time), depending on load • Power – 110 – 240VAC +/-10% supply via PSU • 6 user selectable languages including English, German, French, Spanish, Portuguese and Russian • Accuracy Pipe ID > 75mm – ±0.5% to ±2% of flow reading for flow rate >0.2m/s • Accuracy Pipe ID 13-75mm – ±2% of flow reading for flow rate >0.2m/s • CE approved

Downloads

Portaflow 333 Brochure.pdf

pdf
Download

Portaflow 333 User Manual.pdf

pdf
Download

Specifications

Transducer Operating Temp
‘A’&‘B’ -20°C to +135°C. Optional Hi-Temp -20°C to +200°C.
Outputs
Pulse or Frequency. Opto Isolated MOSFET relay. 4-20mA flow proportional output, optically isolated 1500 volts 620 ohms maximum load.
Data Logging
100,000,000 data points. 12 named sites. Download via USB to CSV file and export to Excel.
