Hanna Instruments Multiparameter (with COD) Photometer and pH Meter 115V For Measuring Key Water and Wastewater Quality Parameters, HI83399-01
Part Number : HI83399-01
Brand :
![Hanna Instruments]()
HI83399 is a compact, multiparameter photometer for measuring key water and wastewater quality parameters. The meter is one of the most advanced photometers available with a innovative optical design that utilizes a reference detector and focusing lens to eliminate errors from changes in the light source and from imperfections in the glass cuvette. 40 key water and wastewater quality parameters with 73 different methods covering multiple ranges are programmed into the meter. Wastewater treatment digestion parameters include COD, Total Nitrogen and Total Phosphorous which are important for monitoring nutrient removal.
View all
KWD 525.000
Description
HI83399 benchtop photometer measures 40 different key water and wastewater quality parameters using 73 different methods that allow for multiple ranges and variations in chemistry for specific applications. The Chemical Oxygen Demand (COD) parameter is included for industrial and municipal wastewater treatment. The Phosphorous and Nitrogen parameters included are beneficial to municipal wastewater treatment customers that need to monitor their biological and chemical nutrient removal process. This photometer features an innovative optical system that uses LEDS, narrow band interference filters, focusing lens and both a silicon photodetector for absorbance measurement and a reference detector to maintain a consistent light source ensures accurate and repeatable photometric readings every time.
A digital pH electrode input is provided allowing the user to measure pH by a traditional glass electrode. The digital pH electrode has a built in microchip within the probe that stores all of the calibration information. Having the calibration information stored in the probe allows for hot swapping of pH electrodes without having to recalibrate. All pH measurements are automatically compensated for temperature variations with a built in thermistor located in the tip of the sensing bulb for fast and accurate temperature measurement.
Two USB ports are provided for transferring data to a flash drive or computer and to use as a power source for the meter. For added convenience and portability the meter can also operate on an internal 3.7 VDC Lithium-polymer rechargeable battery.
The HI83399 offers an absorbance measuring mode that allows for CAL Check standards to be used to validate the performance of the system. The absorbance mode allows the user to select one of the 5 wavelengths of light (420 nm, 466 nm, 525 nm, 575 nm, and 610 nm) to measure and plot their own concentration versus absorbance mode. This is useful for users with their own chemical method and for education to teach the concept of absorbance by using the Beer-Lambert Law.Please note, reagents are not included and can be purchased here.
Ordering Information
HI83399-01 (115V) and HI83399-02 (230V) is supplied with sample cuvette (4 pcs.), sample cuvette cap (4 pcs., cloth for wiping cuvettes, scissors, USB cable, 5 Vdc power adapter, 16mm vial adapter, 16mm diameter vial with cap (6 pcs.), 60mL glass bottle, instrument quality certificate, and instruction manual.
Features and Benefits
- Built-in Reaction Timer
• Automatically takes readings after countdown ends.
• Ensures consistent reaction timing across users.
- Absorbance Mode
• CAL Check for validating light source and detector.
• Enables concentration vs. absorbance plotting for teaching or analysis.
- Units of Measure
• Displays the correct unit with its chemical form for each reading.
- Result Conversion
• Converts readings to other chemical forms at the press of a button.
- Cuvette Cover
• Prevents stray light from affecting readings.
- Digital pH Electrode Input
• Measures both pH and temperature with one probe.
• GLP support: Tracks date, time, buffers, slope, and offset.
• pH CAL Check alerts for calibration problems.
• Saves space by combining pH meter and photometer.
- Data Logging
• Stores up to 1000 readings with a LOG button.
• Sample and user IDs can be added to logs.
- Connectivity
• Transfers data to USB flash drive or PC via micro USB.
• Export logs as .CSV files for spreadsheet use.
- Battery Status
• Displays battery life remaining.
- Error Messages
• Photometric errors: missing cap, high zero, low standard.
• pH calibration errors: clean electrode, check buffer/probe.
Cuvette Adapter
The HI83399 is supplied with a 16 mm cuvette adapter that accepts digestion vials.
Innovative Design
HI83399 is designed with an innovative optical system that incorporates a beam splitter so that light can be used for absorbance readings and for a reference detector. The reference detector monitors the intensity of light and modulates when there is drift due to power fluctuation or the heating of the optical components. Each part has an important role in providing unparalleled performance from a photometer.
High Efficiency LED Light Source
An LED light source offers superior performance as compared to a tungsten lamp. LEDs have a much higher luminous efficiency, providing more light while using less power. They also produce very little heat, which could otherwise affect the optical components an electronic stability. LEDs are available in a wide array of wavelengths, whereas tungsten lamps are supposed to be white light (all wavelengths of visible light) but actually have a poor blue/violet light output.Specifications
