Fluke 15B+ Digital Multimeter, 1000 V, 10 A

Part Number : 15B+ ESP

Brand :
Fluke

Compact and reliable, this digital multimeter is great for electricians and DIY enthusiasts to diagnose electrical issues across various systems while prioritizing accuracy and safety. Additionally, this multimeter features a CAT III 600 V safety rating plus a backlight and measures voltage up to 1000 V and current up to 10 A.

View all

KWD 40.300

Quantity
Description
Specifications
Downloads
Related products

Description

Fluke 15B+ ESP OffersUnlock professional-grade precision, durability, and safety with the Fluke 15B+ digital multimeter. This meter packs all the core functionality you need in a digital multimeter into a portable, rugged form tool that’s easy to use with one hand, even with gloves on. From AC/DC voltage and current measurements up to 1000 V and 10 A, to comprehensive capabilities including resistance, capacitance, and frequency checks, this digital multimeter is your go-to for troubleshooting a wide array of electrical issues.The CAT III 600 V safety rating provides peace of mind for everything from routine checks on electrical equipment and appliances, to checking voltage levels at power outlets or switches, to diagnosing issues with circuits. Ideal for both DIY enthusiasts and early career electricians looking to streamline their toolkit, this digital multimeter is a reliable and versatile addition to your toolkit.FeaturesStandard measurement functions for well-rounded multimeter plus microampsStable measurement accuracy over timeAdvanced measurement functions that is common on more expensive metersAdvanced features such as relative mode to capture deviations in circuits and electronicsUseful for checking flame sensors on furnacesTroubleshoot electrical issues in a wide range of systems with voltage, resistance, continuity, capacitanceCAT III 600 V safety rating: Ensuring your safety when working on electrical systems in common residential, commercial, and industrial settingsLarge easy-to-read display with bright white backlight: Making it easy to read measurements in any lighting condition, even in dimly lit areasResistance, continuity, capacitance: Essential measurement functions for troubleshooting electrical issues in a wide range of systems, allowing you to quickly diagnose and repair problemsDiode Test: Allows you to quickly and accurately identify faulty diodes, saving you time and money on repairsAC/DC voltage and current measurements up to 1000 V and 10 A: Allowing you to get accurate readings for a variety of electrical applicationsInput terminal for AC and DC current measurements to 10 A currentDiagnose electrical problems such as overloading, short circuits, and faulty wiringData holdDurable plastics and robust rotary dialEssential measurement functionsApplicationsEntry level frontline techniciansEntry level electriciansEntry level contractors

Downloads

Fluke_Multimeter_Datasheet_16.pdf

pdf
Download

Specifications

Volts
AC: Range: 4 V, resolution: 0.001 V, accuracy: ±(1% + 3) Range: 40 V, resolution: 0.01 V, accuracy: ±(1% + 3) Range: 400 V, resolution: 0.1 V, accuracy: ±(1% + 3) Range: 1000 V, resolution: 1 V, accuracy: ±(1% + 3) Overload protection: 1000 V Input impedance (nominal): >10 MΩ, <100 pF Common mode rejection ratio: >60 dB at DC, 50 or 60 Hz DC: Range: 4 V, resolution: 0.001 V, accuracy: ±(0.5% + 3) Range: 40 V, resolution: 0.01 V, accuracy: ±(0.5% + 3) Range: 400 V, resolution: 0.1 V, accuracy: ±(0.5% + 3) Range: 1000 V, resolution: 1 V, accuracy: ±(0.5% + 3) Overload protection: 1000 V Input impedance (nominal): >10 MΩ, <100 pF Common mode rejection ratio: >100 dB at dc, 50 or 60 Hz Normal mode rejection ratio: >60 dB at 50 or 60 Hz
Millivolts
AC: Range: 400 mV Resolution: 0.1 mV Accuracy: ±(3% + 3) Overload protection: 400 mV Input impedance (nominal): >1 MΩ, <100 pF Common mode rejection ratio: >80 dB at 50 or 60 Hz DC: Range: 400 mV Resolution: 0.1 mV Accuracy: ±(1% + 10) Overload protection: 400 mV Input impedance (nominal): >1 MΩ, <100 pF Common mode rejection ratio: >80 dB at 50 or 60 Hz
Diode Test*
Range: 2 V Resolution: 0.001 V Accuracy: ±10%*Typically, open circuit test voltage is 2 V and short circuit current is <0.6 mA
Resistance
Range: 400 Ω, resolution: 0.1 Ω, accuracy: ±(0.5% + 3) Range: 4 kΩ, resolution: 0.001 kΩ, accuracy: ±(0.5% + 2) Range: 40 kΩ, resolution: 0.01 kΩ, accuracy: ±(0.5% + 2) Range: 400 kΩ, resolution: 0.1 kΩ, accuracy: ±(0.5% + 2) Range: 4 MΩ, resolution: 0.001 MΩ, accuracy: ±(0.5% + 2) Range: 40 MΩ, resolution: 0.01 MΩ, accuracy: ±(1.5% + 3)
Capacitance*
Range: 40 nF, resolution: 0.01 nF, accuracy: ±(2% + 5) Range: 400 nF, resolution: 0.1 nF, accuracy: ±(2% + 5) Range: 4 µF, resolution: 0.001 µF, accuracy: ±(5% + 5) Range: 40 µF, resolution: 0.01 µF, accuracy: ±(5% + 5) Range: 400 µF, resolution: 0.1 µF, accuracy: ±(5% + 5) Range: 1000 µF, resolution: 1 µF, accuracy: ±(5% + 5) *Specifications do not include errors due to test lead capacitance and capacitance floor (may be up to 1.5 nF in the 40 nF range)
Current µA (40 to 400 Hz)
AC: Range: 400 μA, resolution: 0.1 μA, accuracy ±(1.5% + 3) Range: 4000 μA, resolution: 1 μA, accuracy: ±(1.5% + 3)_x000D_ DC: Range: 400 μA, resolution: 0.1 μA, accuracy ±(1.5% + 3) Range: 4000 μA, resolution: 1 μA, accuracy: ±(1.5% + 3)_x000D_
AC Current (40 to 400 Hz)
mA: Range: 40 mA, resolution: 0.01 mA, accuracy: ±(1.5% + 3) Range: 400 mA, resolution: 0.1 mA, accuracy: ±(1.5% + 3) A: Range: 4 A, resolution: 0.001 A, accuracy: ±(1.5% + 3) Range: 10 A, resolution: 0.01 A, accuracy: ±(1.5% + 3)
Maximum Voltage Between any Terminal and Earth Ground
1000 V
Display
LCD 4000 counts, updates 3 seconds Backlight: Yes
Altitude
Operating: 6562' (2000 m) Storage: 39,370' (12,000 m)
Fuse Protection for Current Inputs
440 mA, 1000 V fast fuse, Fluke specified part only 11 A, 1000 V fast fuse, Fluke specified part only
Power
Battery type: 2 x AA, NEDA 15 A, IEC LR6 Battery life: 500 hours minimum
Environmental Conditions
Operating temperature: 32 to 104°F (0 to 40 °C) Storage: -22 to 140°F (-30 to 60°C) Operating humidity: ≤90% RH at 50 to 86°F (10 to 30°C); ≤75% RH at 86 to 104 °F (30 to 40°C), non-condensing <50°F (<10°C) Operating humidity 40 MΩ range: ≤80% RH at 50 to 86°F (10 to 30°C); ≤70% RH at 86 to 104°F (30 to 40°C) Temperature coefficient: 0.1 x (specified accuracy) /°C (<64.4 or >82.4°F (<18 or >28°C)
Certifications
IP rating: IP40 Safety: IEC 61010-1, IEC 61010-2-030 CAT III 600 V, Pollution Degree 2 Electromagnetic compatibility: IEC 61326-1: Portable EMC Environment
Dimensions
7.2 x 3.6 x 1.95" (183 x 91 x 49.5 mm)
Weight
1 lbs (455 g)
