Emerson Tescom PH2600 Single Stage Regulators, Made with durable Stainless Steel, Spring (handknob), 0 -10, 25, 50, 100, 150 psig / 0.69, 1.7, 3.4, 6.9, 10.3 bar Spring Bias and Dome: 0-100 psi / 0-6.9 bar

Brand :
Tescom

PH-2600 Series is part of our Pharmpure product line. This high purity single-stage regulator offers a compact, USP Class VI and BPE compliant design suitable for specialty, corrosive, and pyrophoric applications. This regulator offers gas flows of < 10 SCFM / 283 SLPM. Diffusion-resistant metal diaphragm seal ensures gas purity and integrity. Ideal for use in sparge gases, clean steam for sanitization, transfer panels and low flow specialty gases.

View all
Quantity
Description
Specifications
Downloads
Related products

Description

Emerson TESCOM PH-2600 Series is part of our Pharmpure product line. This high purity single-stage regulator offers a compact, USP Class VI and BPE compliant design suitable for specialty, corrosive, and pyrophoric applications. This regulator offers gas flows of < 10 SCFM / 283 SLPM. Diffusion-resistant metal diaphragm seal ensures gas purity and integrity. Ideal for use in sparge gases, clean steam for sanitization, transfer panels and low flow specialty gases. The Emerson TESCOM PH2600 Single Stage Regulators is engineered to provide outstanding performance and reliability. It is ideal for a wide range of applications, offering exceptional durability and efficiency. Key specifications and features make it a top choice for professionals worldwide.

Features

• 316L Stainless Steel barstock regulator body design • FDA/USP compliant designs are available • Clean Service Certification of Compliance available: Includes actual material certification, weld records, and bill of materials • 15 or 32 Ra microinch / 0.38 or 0.81 micrometer body surface finishes are available • Precise pressure control • Gauge port is available • ASME BPE 2009 compliant design

Downloads

TESCOM_ PH2600 Single Stage Regulators_datasheet_2.pdf

pdf
Download

Specifications

Outlet Pressure Ranges
Spring (handknob): 0 -10, 25, 50, 100, 150 psig / 0.69, 1.7, 3.4, 6.9, 10.3 bar Spring Bias and Dome: 0-100 psi / 0-6.9 bar (See Part Number Selector for more details)
Material
Choose a housing material that is not corroded by the media and environment , and can withstand the temperatures and pressures. Check out our chemical resistance chart.
Body: 316L Stainless Steel Seat: Teflon , PEEK-OPTIMA or PEEK-Classix Valve Guide, Diaphragm: 316 Stainless Steel Seat Retainer: Nitronic 60
Friction Sleeve
Inner: Teflon Outer: 316 Stainless Steel
Remaining Parts
316 Stainless Steel
Operating Temperature (Media Only)
Teflon Seat: -40°F to 165°F / -40°C to 74°CPEEK-OPTIMA or Peek-Classix Seat: -40°F to 400°F / -40°C to 204°C
Port Size & Type
Inlet & Outlet Port Type: Sanitary, Tube Inlet & Outlet Port Size: 3/8 (Tube Only), 1/2
Flow Capacity
Cv = 0.02, 0.06, 0.15, 0.24
Load Type
Spring, Spring Bias, Dome
Weight (approximately)
2.0 lbs / 0.9 kg
Additional Information
For custom modifications or a complete system solution, please contact your local sales office.
