Emerson Tescom 44-1500 Low-Pressure Regulator, Stainless Steel Body, Spring Load: 0-200, 0-400 psig / 0-14, 0-28 bar, Air/Dome Load: 0-600 psig / 0-41 bar

Brand :
Tescom

44-1500 Series high flow/low pressure regulator controls outlet pressures up to 600 psig / 41 bar. Large area piston provides accurate pressure control and cycle life superior to diaphragm sensed regulators when applied to heavy duty cycling. Features a segregated / captured vent for hydraulic or pneumatic media and is available in two outlet spring ranges. Optional dome or air loaded versions for remote operation or for use with the ER5000 Electropneumatic Controller for automation. Ideal for use in hydraulic and pneumatic testing.

View all
Quantity
Description
Specifications
Downloads
Related products

Description

Emerson TESCOM 44-1500 Series high flow/low pressure regulator controls outlet pressures up to 600 psig / 41 bar. Large area piston provides accurate pressure control and cycle life superior to diaphragm sensed regulators when applied to heavy duty cycling. Features a segregated / captured vent for hydraulic or pneumatic media and is available in two outlet spring ranges. Optional dome or air loaded versions for remote operation or for use with the ER5000 Electropneumatic Controller for automation. Ideal for use in hydraulic and pneumatic testing. The Emerson TESCOM 44-1500 Low-Pressure Regulator is engineered to provide outstanding performance and reliability. It is ideal for a wide range of applications, offering exceptional durability and efficiency. Key specifications and features make it a top choice for professionals worldwide.

Features

• For gaseous and liquid media • Segregated and Captured vent design is standard • Balanced valve design ensures stable downstream pressure • 6000 psig / 414 bar maximum inlet • Low droop • Large sensor for accurate pressure control • High flow, low outlet pressures • Compatible with TESCOM ER5000 Electropneumatic Controller

Downloads

TESCOM_ 44_1500 Low_Pressure Regulator_datasheet_2.pdf

pdf
Download

Specifications

Outlet Pressure Ranges
Spring Load: 0-200, 0-400 psig / 0-14, 0-28 bar  Air/Dome Load: 0-600 psig / 0-41 bar
Material
Choose a housing material that is not corroded by the media and environment , and can withstand the temperatures and pressures. Check out our chemical resistance chart.
Body: 316 Stainless Steel or Brass 40 Micron Filter: Bronze Main and Vent Valve Seats: Vespel SP21 Back-up Rings: Teflon
O-Ring
Buna-N, Viton , Kalrez , Ethylene Propylene
Remaining Parts
300 Series Stainless Steel, Brass, Monel
Ambient Operating Temperature
-15°F to 165°F / -26°C to 74°C
Port Size & Type
Inlet & Outlet Port Size: 3/8, 1/2 Inlet & Outlet Port Type: SAE, NPTF, MS33649Vent Port: 1/4 SAE, 1/4 NPTF, 1/4 MS33649
Flow Capacity
Cv = 0.3
Load Type
Air, Dome, Spring
Weight
4.75 lbs / 2.2 kg
