Applied Membranes Inc Direct SDI Portable Silt Density Index Water Testing Kit SDI-2000 with On-site Carrying Case and 2 SDI Test Filters

Part Number : SDI-2000

Brand :
Applied Membranes Inc

AMI’s direct SDI test kit is completely assembled in a portable, compact case, ready for on-site testing. Quick-Connect In and Out connections are built into product panel for fast and easy connection and disconnection on site. Includes ASTM instructions for measuring silt density index. Minimum of 30 PSI water pressure required. Optional Pump Assembly Kits are offered for pressures below 30 PSI.

View all

$ 950.000

Quantity
Description
Specifications
Downloads
Related products

Description

Direct SDI Portable Silt Density Index Test Kit (SDI Tester) SDI-2000 is completely assembled in a portable, compact case, ready for on-site testing. Suspended solids and colloidal materials in feed water are one of the biggest problems in reverse osmosis systems. Silt Density Index (SDI) is the established measurement of this fouling problem, in which a 0.45 micron filter is exposed to the feed water under pressure and filtration rates are calculated. In most cases, an SDI of less than 5 is considered acceptable for the reverse osmosis systems. SDI-2000 Silt Density Index test kit includes two SDI filters. An additional filter pack (SDI-045) should also be purchased. SDI Test Kit Assembly Includes: Filter Holder, Pressure Gauge, Pressure Regulator, Ball Valve, Graduated Cylinder, Thermometer, Tubing, Filter Tweezers and ASTM SDI Test Instructions.

Features

• Ensure optimum performance of reverse osmosis systems by verifying the feed water SDI is within acceptable limits.

• SDI Testing before a system installation can determine any pretreatment required during system design.

• Test manifold is built into a portable travel case with easy connection/disconnection for on-site testing.

• Optional booster pump assembly (sold separately) is available for testing feed sources with pressures below 30 psi.

• Manufactured in our ISO 9001:2015 Certified Facilities

• Completely assembled in a portable contact case.

• Quick Connect Style In/Out connections built into the product panel for fast and easy connection/disconnection

Benefits

• PROTECT YOUR REVERSE OSMOSIS SYSTEM: High levels of silt and other solids in the water source you’re connecting your RO filtration system to can cause damage over time. This portable water-quality test kit includes 2 SDI filter tests to check water on-site and aid in determining pretreatment requirements.

• PRO-LEVEL ON-SITE TESTING IN 1 CASE: Our water-testing kit for water treatment and system feed water comes with everything you need to measure silt density on-site in 1 case, including two 0.45 micron filters. An SDI of less than 5 is acceptable for reverse osmosis systems.

• INSTANT TEST RESULTS: Follow the included simple step-by-step instructions to obtain immediate test results on-site without sending water to a lab for analysis. The test takes approximately 20 minutes, including setup.

• READY TO USE: This kit includes ASTM instructions for measuring silt density index to help you get accurate results. A minimum of 30 PSI water pressure is required to use this kit. We also sell Pump Assembly Kits to use with lower pressures.

• CLEAN WATER IS OUR MISSION: Applied Membranes has been bringing clean water to facilities worldwide for over 40 years. AMI Silt Density Index Testers are made in the United States in our ISO 9001:2015-quality certified facilities.

SDI Test Kit Assembly Includes:

• Filter Holder

• Pressure Gauge

• Pressure Regulator

• Ball Valve

• Graduated Cylinder

• Thermometer

• Tubing

• Filter & Tweezers

• ASTM SDI Test Instructions

• SDI-2000 Silt Density Index test kit includes two SDI filters

SDI (Silt Density Index) Testing Applications

• Reverse Osmosis

• UltraFiltration

• MicroFiltration

Downloads

Datasheet SDI-2000.pdf

pdf
Download

SDi-2000 Testing Instructions.pdf

pdf
Download

Specifications

Product Dimensions
11 x 11 x 6 inches
Weight
2.260 Kg
Certifications
ISO 9001:2015 Certified
Applications
Reverse Osmosis, Ultra Filtration, Micro Filtration
