Thermal Imagers
13
results
|
Product
|
Accuracy
|
Standard
|
Temperature
|
Battery
|
Vibration
|
Display
|
Type
|
Operating Temperature
|
Environmental Conditions
|
Frame rate
|
|---|
|
|
±2°C or 2% (whichever is greater) at 25°C ambient temperature | Operating: 14 to 122°F (-10 to 50°C) Storage: -4 to 122°F (-20 to 50°C) without batteries | Type: Lithium-ion rechargeable battery Life: ≥3.5 hours continuous without WiFi (actual life depends on settings and usage) Charging time: ≤2.5 hours to full charge | 10 to 150 Hz, 0.15 mm, IEC 60068-2-6 | 3.5" (8.9 cm landscape) touchscreen 640 x 480 LCD | 27 Hz | |||||
|
|
Target temp at or over 0°C: Accuracy: ±2°C or ±2% at 25°C, whichever is the greater | 3.5" LCD touchscreen (landscape) | Lithium ion smart battery pack with five-segment LED display to show charge level | 14 to 122°F (-10 to 50°C) | 9 Hz | ||||||
|
|
Target temperature at or over 32°F: Accuracy: ±35.6°C or ±2% at 77°C, whichever is the greater Target temperature at or over 0°C: Accuracy: ±2°C or ±2% at 25°C, whichever is the greater | 6: Ironbow, blue-red, high contrast, amber, hot metal, grayscale | Operating: 14 to 122°F (-10 to 50°C) Storage: -40 to 158°F (-40 to 70°C) | Type: Lithium ion smart battery pack with five-segment LED display to show charge level Life: ≥5 hours continuous (without WiFi) Charging time: 2.5 hours to full charge AC operation: AC operation with included power supply (100 to 240 V AC, 50/60 Hz) Power saving: Automatic shutdown: 5, 10, 15 and 20 minutes or never | 3.5" LCD touchscreen (landscape) | 9 Hz | |||||
|
|
±35.6°F or 2% (at 77°F nominal, whichever is greater) ±2°C or 2% (at 25°C nominal, whichever is greater) | 8: Ironbow, blue-red, high contrast, amber, amber inverted, hot metal, grayscale, grayscale inverted | Operating: 14 to 122°F (-10 to 50°C) Storage: -4 to 122°F (-20 to 50°C) without batteries | Type (field-replaceable, rechargeable): 2 x lithium ion smart battery pack with five-segment LED display to show charge level Life: 4 hours continuous use per battery pack Charging time: 2.5 hours to full charge AC Operation: AC operation with included power supply (100 to 240 V AC, 50/60 Hz) Power saving: User selectable | 2G, IEC 68-2-6 | 30 Hz | |||||
|
|
±2°C or 2% (at 25°C nominal, whichever is greater) | 9: rainbow, ironbow, blue-red, high contrast, amber, amber inverted, hot metal, grayscale, grayscale inverted | Operating: 14 to 122°F (-10 to 50°C) Storage: -4 to 122°F (-20 to 50°C) without batteries | Type: 2 x lithium ion smart battery packs with five-segment LED display to show charge level Life: 2 to 3 hours per battery (Actual life varies depending on settings and usage) Charge time: 2.5 hours to full charge Charging system: Two-bay battery charger or in-imager charging | 0.03 g2/Hz (3.8 g), 2.5 g IEC 68-2-6 | ||||||
|
|
Target temperature at or over 0°C: Accuracy: ±2°C or ±2% at 25°C, whichever is the greater | Operating: 14 to 122°F (-10 to +50°C) Storage: -40 to 158°F (-40 to +70°C) | Type: Internal rechargeable lithium ion battery Life: >2 hours continuous (without Wi-Fi) System: Micro USB port | 3.5" (8.89 cm) LCD touchscreen (landscape) Resolution: 320 x 240 | 9 Hz | ||||||
|
|
±2°C or 2% (at 25°C nominal, whichever is greater) | 9: Rainbow, ironbow, blue-red, high contrast, amber, amber inverted, hot metal, grayscale, grayscale inverted | Type: 2 x lithium ion smart battery packs with five-segment LED display to show charge level Life: Two to three hours per battery (actual life varies depending on settings and usage) Charging time: 2.5 hours to full charge Charging system: 2 x bay battery chargers or in-imager charging AC operation with included power supply (100 to 240 V AC, 50/60 Hz) Power saving: User selectable sleep and power off modes | 0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6 | Operating temperature: 14 to 122°F (-10 to 50°C) Storage temperature: -4 to 122°F (-20 to 50°C), without batteries Relative humidity: 10 to 95%, non-condensing | 60 Hz | |||||
|
|
±2°C or 2% (at 25°C nominal, whichever is greater) | 9: Rainbow, ironbow, blue-red, high contrast, amber, amber inverted, hot metal, grayscale, grayscale inverted | Operating: 14 to 122°F (-10 to 50°C) Storage: -4 to 122°F (-20 to 50°C) without batteries | Type: 2 x lithium ion smart battery packs with five-segment LED display to show charge level Life: 2 to 3 hours per battery (actual life varies depending on settings and usage) Charging time: 2.5 hours to full charge Charging system: Two-bay battery charger or in-imager charging | 0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6 | ||||||
|
|
±35.6°F or 2% (whichever is greater) at 77°F ambient temperature ±2°C or 2% (whichever is greater) at 25°C ambient temperature | Operating: 14 to 122°F (-10 to 50°C) Storage: -4 to 122°F (-20 to 50°C) without batteries | Type (field-replaceable, rechargeable): Lithium-ion rechargeable battery Life: ≥3.5 hours continuous without WiFi (actual life depends on settings and usage) Charging time: ≤2.5 hours to full charge AC operation: AC operation with included power supply, universal adapters included output: 15 VDC, 2 A Power saving: User-selectable sleep and power off | 10 to 150 Hz, 0.15 mm, IEC 60068-2-6 | 3.5" (8.9 cm landscape) touchscreen 640 x 480 LCD | 27 Hz | |||||
|
|
±2°C or 2% (at 25°C nominal, whichever is greater) | 8: Ironbow, blue-red, high contrast, amber, amber inverted, hot metal, grayscale, grayscale inverted | Type: 2 x lithium ion smart battery packs with five-segment LED display to show charge level Life: Two to three hours per battery (actual life varies depending on settings and usage) Charge time: 2.5 hours to full charge Charging system: Two-bay battery charger or in-imager charging AC operation with included power supply (100 to 240 V AC, 50/60 Hz) Power saving: User selectable sleep and power off modes | 0.03 g2/Hz (3.8 g), 2.5 g IEC 68-2-6 | 9 Hz | ||||||
|
|
±2°C or 2% (at 25°C nominal, whichever is greater) | 8: ironbow, blue-red, high contrast, amber, amber inverted, hot metal, grayscale, grayscale inverted | Operating: 14 to 122°F (-10 to 50°C) Storage: -4 to 122°F (-20 to 50°C) without batteries | Type: 2 x lithium ion smart battery packs with five-segment LED display to show charge level Life: 2 to 3 hours per battery (Actual life varies depending on settings and usage) Charge time: 2.5 hours to full charge Charging system: Two-bay battery charger or in-imager charging | 0.03 g2/Hz (3.8 g), 2.5 g IEC 68-2-6 | ||||||
|
|
±2°C or ±2%, whichever is greater | Operating: 14 to 122°F (-10 to 50°C) Storage: -4 to 122°F (-20 to to 50°C) | 60 Hz | ||||||||
|
|
±2°C or ±2%, whichever is greater | Operating: 14 to 122°F (-10 to 50°C) Storage: -4 to 122°F (-20 to to 50°C) | 60 Hz |
Thermal Imagers
Thermal Imagers, also known as infrared cameras, are advanced tools designed to visualize temperature variations by capturing infrared radiation. These devices are indispensable across industries, offering accurate thermal imaging solutions for inspections, diagnostics, and monitoring.
Applications of Thermal Imagers:
- Building Diagnostics: Identify structural issues, insulation gaps, and detect moisture intrusion to enhance building integrity.
- Electrical/Mechanical Inspections: Prevent equipment failures by pinpointing electrical or mechanical hotspots.
- HVAC/R Inspections: Ensure optimal system performance and energy efficiency by detecting airflow issues and leaks.
- Manufacturing: Monitor production processes and improve quality assurance with precise temperature measurements.
- Oil and Gas: Safeguard operations and detect pipeline leaks or irregularities in challenging environments.
- Research and Development: Analyze heat patterns in prototypes and ensure accurate scientific testing.
- Utilities: Conduct inspections of power lines, substations, and transformers to prevent outages and ensure safety.
Featured Products:
- Building Diagnostics Thermal Cameras
- Electrical and Mechanical Inspection Infrared Tools
- HVAC/R Inspection Infrared Cameras
- Manufacturing Process Thermal Imagers
- Oil and Gas Exploration Infrared Cameras
- Research and Development Infrared Cameras
- Utility Inspection Infrared Tools
Each of these thermal imaging devices is crafted to deliver exceptional accuracy and durability, making them ideal for professionals seeking reliability in their tools. Whether it's troubleshooting electrical systems or conducting research, thermal imagers simplify complex tasks and improve efficiency across diverse domains.
