Needle Valves

Subcategories

Compact Body Needle Valves

Compact Body Needle Valves

Gauge Root Valves

Gauge Root Valves

High-Pressure Needle Valves

High-Pressure Needle Valves

Precision Flow Control Needle Valves

Precision Flow Control Needle Valves

Severe Service Needle Valves

Severe Service Needle Valves

Standard Needle Valves

Standard Needle Valves

Toggle Needle Valves

Toggle Needle Valves

Utility Needle Valves

Utility Needle Valves

295 results

Product	Series	End Connection	Size Inlet x Outlet	Description	Orifice Size	Handle	Valve Pattern	End Connections	Valve Material	Packing Material

DK-Lok V15 Series Needle Valve, 2 mm Orifice, 1/8" Female NPT x 1/8" Female NPT, V15A-F-2N-S V15A-F-2N-S	2 mm Orifice		1/8" Female NPT x 1/8" Female NPT	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Female NPT
DK-Lok V15 Series Needle Valve, 2 mm Orifice, 1/8" Male NPT x 1/8" Male NPT, V15A-M-2N-S V15A-M-2N-S	2 mm Orifice		1/8" Male NPT x 1/8" Male NPT	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Male NPT
DK-Lok V15 Series Needle Valve, 2 mm Orifice, 1/8" Male NPT x 1/8" Tube OD, V15A-MD-2N2T-S V15A-MD-2N2T-S	2 mm Orifice		1/8" Male NPT x 1/8" Tube OD	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Male NPT, Tube OD
DK-Lok V15 Series Needle Valve, 2 mm Orifice, 1/8" Tube OD x 1/8" Tube OD, V15A-D-2T-S V15A-D-2T-S	2 mm Orifice		1/8" Tube OD x 1/8" Tube OD	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Tube OD
DK-Lok V15 Series Needle Valve, 2 mm Orifice, 3mm Tube OD x 3mm Tube OD, V15A-D-3M-S V15A-D-3M-S	2 mm Orifice		3mm Tube OD x 3mm Tube OD	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Tube OD
DK-Lok V15 Series Needle Valve, 4.3 mm Orifice, 1/8" Female NPT x 1/8" Female NPT, V15B-F-2N-S V15B-F-2N-S	4.3 mm Orifice		1/8" Female NPT x 1/8" Female NPT	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Female NPT
DK-Lok V15 Series Needle Valve, 4.3 mm Orifice, 1/8" Male NPT x 1/8" Male NPT, V15B-M-2N-S V15B-M-2N-S	4.3 mm Orifice		1/8" Male NPT x 1/8" Male NPT	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Male NPT
DK-Lok V15 Series Needle Valve, 4.3 mm Orifice, 1/4" Male NPT x 1/4" Male NPT, V15B-M-4N-S V15B-M-4N-S	4.3 mm Orifice		1/4" Male NPT x 1/4" Male NPT	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Male NPT
DK-Lok V15 Series Needle Valve, 4.3 mm Orifice, 1/4" Male NPT x 1/4" Tube OD, V15B-MD-4N4T-S V15B-MD-4N4T-S	4.3 mm Orifice		1/4" Male NPT x 1/4" Tube OD	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Male NPT, Tube OD
DK-Lok V15 Series Needle Valve, 4.3 mm Orifice, 6mm Tube OD x 6mm Tube OD, V15B-D-6M-S V15B-D-6M-S	4.3 mm Orifice		6mm Tube OD x 6mm Tube OD	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Tube OD
DK-Lok V15 Series Needle Valve, 4.3 mm Orifice, 1/4" Tube OD x 1/4" Tube OD, V15B-D-4T-S V15B-D-4T-S	4.3 mm Orifice		1/4" Tube OD x 1/4" Tube OD	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Tube OD
DK-Lok V15 Series Needle Valve, 4.3 mm Orifice, 8mm Tube OD x 8mm Tube OD, V15B-D-8M-S V15B-D-8M-S	4.3 mm Orifice		8mm Tube OD x 8mm Tube OD	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Tube OD
DK-Lok V15 Series Needle Valve, 6.4 mm Orifice, 1/4" Female NPT x 1/4" Female NPT, V15C-F-4N-S V15C-F-4N-S	6.4 mm Orifice		1/4" Female NPT x 1/4" Female NPT	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Female NPT
DK-Lok V15 Series Needle Valve, 6.4 mm Orifice, 3/8" Male NPT x 3/8" Male NPT, V15C-M-6N-S V15C-M-6N-S	6.4 mm Orifice		3/8" Male NPT x 3/8" Male NPT	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Male NPT
DK-Lok V15 Series Needle Valve, 6.4 mm Orifice, 1/4" Male NPT x 3/8" Tube OD, V15C-MD-4N6T-S V15C-MD-4N6T-S	6.4 mm Orifice		1/4" Male NPT x 3/8" Tube OD	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Male NPT, Tube OD
DK-Lok V15 Series Needle Valve, 6.4 mm Orifice, 3/8" Male NPT x 3/8" Tube OD, V15C-MD-6N6T-S V15C-MD-6N6T-S	6.4 mm Orifice		3/8" Male NPT x 3/8" Tube OD	Forged body, Pressure Rating up to 5000 psig (345 bar) Integral Bonnet Needle Valves FOR REGULATING and SHUT-OFF			Inline	Male NPT, Tube OD

5502508Needle Valve Category.webp

Description

Needle valves are precision-engineered flow control devices designed to regulate the flow of fluids or gases in a system. They are known for their reliability, durability, and ability to ensure precise flow adjustments, making them an essential component in various industrial applications. Needle valves feature a slender, tapered needle-like stem that fits into a matching seat, allowing operators to finely control flow rates by adjusting the stem. Indspare offers a comprehensive range of needle valves to cater to diverse needs and applications. The Compact Body Needle Valves are ideal for tight spaces, providing efficient flow control in compact systems. The Gauge Root Valves are designed to isolate and protect pressure instruments, ensuring accuracy and safety in pressure measurement applications. For high-pressure environments, the High-Pressure Needle Valves provide robust performance and leak-free operation even under extreme conditions. The Precision Flow Control Needle Valves are crafted for applications requiring ultra-precise flow regulation, making them suitable for laboratory or analytical systems. Severe Service Needle Valves are built to withstand harsh environments and demanding conditions, delivering exceptional durability and performance. The Standard Needle Valves are versatile and widely used across general industrial applications due to their reliable construction. For quick operation, Toggle Needle Valves provide easy on/off control with a simple toggle handle, enhancing convenience in systems requiring frequent adjustments. Lastly, the Utility Needle Valves are designed for cost-effective and versatile flow control solutions in a variety of applications. With their diverse range, Indspare’s needle valves are perfect for industries like oil and gas, chemical processing, power generation, and more, ensuring optimal performance and precision in every application.
