Gefran Melt Pressure Transmitter with Thermocouple for High Temperature Environment, ME2-6-H-P05M-1-4-D
Part Number : ME2-6-H-P05M-1-4-D
Brand :
![Gefran]()
The ME2 series of Gefran, are pressure transmitters for using in High temperature environment. The main characteristic of this series is the capability to read temperature of the media up to 400°C. The constructive principle is based on the hydraulic trasmission of the pressure. The fluid-filled system assures the temperature stability. The phisical measure is transformed in a electrical measure by means the strain-gauge technology.
View all
KWD 180.000
Description
Gefran Melt Pressure Transmitter with Thermocouple for High Temperature Environment, ME2-6-H-P05M-1-4-D is a high-performance industrial component designed to meet the rigorous demands of modern automation and process control applications. With its advanced design and superior construction, it ensures optimal performance, precision, and reliability. Engineered for seamless integration into industrial systems, this product is built to deliver accurate and consistent operation. It features cutting-edge technology, offering enhanced efficiency and operational stability. Key specifications include: Technical specifications vary based on model selection.. Whether used in manufacturing, monitoring, or process control, this component is an excellent choice for ensuring high standards of functionality and durability.
Key Features
• Pressure ranges from: 0-35 to 0-2000 bar / 0-500 to 0-30000 psi
• Accuracy: < ±0.25% FSO (H); < ±0.5% FSO (M)
• Fluid-filled system for temperature stability
• Mercury filling volume: ME0 (30mm3); ME1, ME2, ME3 (40mm3)
• 1/2-20UNF, M18x1.5 standard threads; other types available on request
• Autozero function on board / external option
• Drift Auto compensation function (SP version)
• Standard diaphragm is 15-5 PH stainless steel with GTP+ coating
• 17-7 PH corrugated diaphragm with GTP+ coating for ranges below 100 bar-1500 psi
Autozero Function
All signal variations in the absence of pressure can be eliminated by using the Autozero function. This function is activated by closing a magnetic contact located on the transmitter housing. The procedure is permitted only with pressure at zero.Specifications
