Trunnion Ball Valves
54
results
|
Product
|
Series
|
End Connection
|
Size Inlet x Outlet
|
Seat Material
|
Service Kit
|
|---|
| 2-Way Valve up to 413 bar (6000 psig) | Female NPT | 1/8" Female NPT x 1/8" Female NPT | PCTFE | No | ||
| 2-Way Valve up to 413 bar (6000 psig) | Female NPT | 1/4" Female NPT x 1/4" Female NPT | PCTFE | No | ||
| 2-Way Valve up to 413 bar (6000 psig) | Female NPT | 1/2" Female NPT x 1/2" Female NPT | PCTFE | No | ||
| 2-Way Valve up to 413 bar (6000 psig) | Tube OD | 1/4" Tube OD x 1/4" Tube OD | PCTFE | No | ||
| 2-Way Valve up to 413 bar (6000 psig) | Tube OD | 3/8" Tube OD x 3/8" Tube OD | PCTFE | No | ||
| 2-Way Valve up to 413 bar (6000 psig) | Tube OD | 1/2" Tube OD x 1/2" Tube OD | PCTFE | No | ||
| 2-Way Valve up to 413 bar (6000 psig) | Tube OD | 6mm Tube OD x 6mm Tube OD | PCTFE | No | ||
| 2-Way Valve up to 413 bar (6000 psig) | Tube OD | 8mm Tube OD x 8mm Tube OD | PCTFE | No | ||
| 2-Way Valve up to 413 bar (6000 psig) | Tube OD | 10mm Tube OD x 10mm Tube OD | PCTFE | No | ||
| 2-Way Valve up to 413 bar (6000 psig) | Tube OD | 12mm Tube OD x 12mm Tube OD | PCTFE | No | ||
| 3-Way Valve up to 413 bar (6000 psig) | Female NPT | 1/8" Female NPT x 1/8" Female NPT | PCTFE | No | ||
| 3-Way Valve up to 413 bar (6000 psig) | Female NPT | 1/4" Female NPT x 1/4" Female NPT | PCTFE | No | ||
| 3-Way Valve up to 413 bar (6000 psig) | Tube OD | 1/4" Tube OD x 1/4" Tube OD | PCTFE | No | ||
| 3-Way Valve up to 413 bar (6000 psig) | Tube OD | 3/8" Tube OD x 3/8" Tube OD | PCTFE | No | ||
| 3-Way Valve up to 413 bar (6000 psig) | Tube OD | 1/2" Tube OD x 1/2" Tube OD | PCTFE | No | ||
| 3-Way Valve up to 413 bar (6000 psig) | Tube OD | 6mm Tube OD x 6mm Tube OD | PCTFE | No |
Trunnion Ball Valves
Trunnion Ball Valves are precision-engineered valves designed for high-performance industrial applications. These valves provide excellent sealing and durability, ensuring reliable operation in high-pressure environments. The unique trunnion-mounted design supports the ball in a stationary position, reducing wear and ensuring long-lasting performance.
Features of Trunnion Ball Valves
- High Pressure Handling: Suitable for applications up to 413 bar (6000 psi).
- Versatile End Connections: Available in Female NPT and Tube OD options to fit diverse system requirements.
- Premium Seat Material: Constructed with PCTFE seat material for exceptional chemical resistance and operational stability.
- Wide Range of Sizes: Connections ranging from 1/8" to 1/2" ensure flexibility for various setups.
Applications
These valves are widely used in industries such as:
- Oil and Gas
- Chemical Processing
- Petrochemical Plants
- Industrial Manufacturing
- Compressed Natural Gas (CNG) systems
Why Choose DK-Lok Trunnion Ball Valves?
DK-Lok’s Trunnion Ball Valves are built to ensure the highest level of safety, performance, and reliability. With a robust design and diverse connection options, they meet the demanding requirements of industrial systems, providing a cost-effective and efficient solution.
