Compression Tube Fittings and Connectors
Subcategories
Product
|
Material
|
D - Tube O.D.
|
E - Min.
|
h - Width Across Flat
|
l
|
Brand
|
---|
|
Stainless Steel 316/316L | 1/16 in 1.6 mm | 1.3 mm | 5/16 in 7.9 mm | 17.5 mm | DK-Lok | |
|
Stainless Steel 316/316L | 1/8 in 3.2 mm | 2.3 mm | 7/16 in 11.1 mm | 22.4 mm | DK-Lok | |
|
Stainless Steel 316/316L | 3/16 in 4.8 mm | 3.0 mm | 7/16 in 11.1 mm | 24.1 mm | DK-Lok | |
|
Stainless Steel 316/316L | 1/4 in 6.4 mm | 4.8 mm | 1/2 in 12.7 mm | 26.2 mm | DK-Lok | |
|
Stainless Steel 316/316L | 5/16 in 7.9 mm | 6.4 mm | 9/16 in 14.3 mm | 28.2 mm | DK-Lok | |
|
Stainless Steel 316/316L | 3/8 in 9.5 mm | 7.1 mm | 5/8 in 15.9 mm | 30.2 mm | DK-Lok | |
|
Stainless Steel 316/316L | 1/2 in 12.7 mm | 10.4 mm | 13/16 in 20.6 mm | 31.0 mm | DK-Lok | |
|
Stainless Steel 316/316L | 5/8 in 15.9 mm | 12.7 mm | 15/16 in 23.8 mm | 31.8 mm | DK-Lok | |
|
Stainless Steel 316/316L | 3/4 in 19.1 mm | 15.7 mm | 1-1/16 in 27.0 mm | 33.3 mm | DK-Lok | |
|
Stainless Steel 316/316L | 7/8 in 22.2 mm | 18.3 mm | 1-3/16 in 30.2 mm | 35.1 mm | DK-Lok | |
|
Stainless Steel 316/316L | 1 in 25.4 mm | 22.4 mm | 1-3/8 in 34.9 mm | 40.4 mm | DK-Lok | |
|
Stainless Steel 316/316L | 1-1/4 in 31.8 mm | 27.7 mm | 1-3/4 in 44.5 mm | 48.0 mm | DK-Lok | |
|
Stainless Steel 316/316L | 1-1/2 in 38.1 mm | 34.0 mm | 2-1/8 in 54.0 mm | 53.6 mm | DK-Lok | |
|
Stainless Steel 316/316L | 2 in 50.8 mm | 46.0 mm | 2-3/4 in 69.9 mm | 74.7 mm | DK-Lok | |
|
Brass | 1/16 in 1.6 mm | 1.3 mm | 5/16 in 7.9 mm | 17.5 mm | DK-Lok | |
|
Brass | 1/8 in 3.2 mm | 2.3 mm | 7/16 in 11.1 mm | 22.4 mm | DK-Lok |
Compression Tube Fittings and Connectors
Compression Tube Fittings and Connectors are essential components in industrial piping systems, ensuring secure, leak-proof, and durable connections. Designed for use in a wide range of applications, these fittings provide precise alignment and reliable sealing under high-pressure and high-temperature conditions. They are commonly used in industries such as oil and gas, chemical processing, power generation, and instrumentation. With compatibility across various tubing materials, these fittings offer easy installation, reusability, and excellent performance, making them ideal for both standard and critical operations.
